Rako RAK8-S eight-channel switching rack
The RAK8-S provides eight relay-switched channels for compatible non-dimmable lighting and other suitable loads. It integrates with a wired system through RAK-LINK or a wireless system through RX-LINK. Installation and commissioning are required.
RAK8-S technical specifications
| Channels | Eight switched channels |
|---|---|
| Supply | 230V AC, 50Hz |
| Dimensions | 193 × 253 × 110mm |
| Protection | 10A Type B MCB protection required |
| Minimum load | Not specified in current datasheet |
| Weight | 3.5kg |
Selection and installation advice
Use for loads requiring switching rather than dimming. Check the load-specific limits and total rack loading in the manufacturer instructions, including motor and transformer limits. Specify the appropriate Rako control interface with the rack.
For the wiring diagram and complete installation requirements, see the Rako RAK8-S manufacturer datasheet.
Planning a system or checking an existing installation? Explore our Rako lighting control range and project advice. Send us the model numbers, room requirements and load or fitting details so we can help specify the right parts.
