RAK4-F Four-Channel Digital Dimming Rack
The RAK4-F combines four switched mains outputs with four configurable digital dimming outputs for compatible 0–10V, DSI or DALI lighting.
RAK4-F technical specifications
| Channels | Four |
|---|---|
| Control outputs | 0–10V, DSI or DALI broadcast |
| Maximum per-channel current | 5A |
| Maximum total current | 10A |
| System interface | RX-LINK or RAK-LINK |
| DALI operation | Broadcast, not individually addressable DALI control |
Selection and installation advice
Match the ballast protocol and provide the separate dimming-control wiring. Use an appropriate addressable DALI controller when individual ballast addressing is needed. Install in a ventilated enclosure location with the clearances specified in the manual.
For full product and installation details, see the Rako RAK4-F manufacturer documentation.
Planning a system or checking an existing installation? Explore our Rako lighting control range and project advice. Send us the model numbers, room requirements and load or fitting details so we can help specify the right parts.
