Purchase this item and get
- Quick and easy installation
- High performance C-CAM tweeter and driver technology
- Robust solid sealed, high density polypropylene enclosure – UV rated.
- Full installation flexibility: 175º rotational bracket, (it also features angled sections and screw holes to provide corner fixing.)
- 15º angled wedge supplied for additional bracket versatility
- Anchor point for security chain attachment
- ABR (Auxiliary Bass Radiator) for added low frequency punch
- Aluminium grilles prevent rust
- *Textured white and black finish, paintable to suit décor (paint mask supplied)
- Rotational ‘M’ logo to align with portrait or landscape positions.
Frequency Response
63Hz – 30KHz
Sensitivity (1W@1m)
88 dB
Impedance (nominal)
8 Ohms
Maximum S.P.L dBA (per pair)
108.8
Power Handling (RMS)
100W
Amplifier Requirements (RMS)
15 – 100W
Drivers
1 x 165mm (6 1/2”) C-CAM® bass/ mid-range driver
1 x 25mm (1”) C-CAM® gold dome tweeter
External Dimensions: (H x W x D)
325 x 185 x 178.5 mm
External Dimensions: (H x W x D)
12 13/16 x 7 5/16 x 7 inches
Total Depth Including Wall Bracket mm (inches)
235 (9 1/4)
Total Bracket Pivot Angle
87.5 degrees (from central position)
Fixed Angled Block (portrait orientation)
15 degrees
Cable Connection
Gold plated ‘push’ type terminals
Environmental Protection Rating
IP55
Finishes Available
White/Black
Weight Packaged: kg
4.62 (10lb 2oz)
